DC split charging station

Product introduction

240KW, 480KW, 600KW, 720KW split charging piles

National/European/American standards are optional;

Product power: 240KW to 720KW optional;

Product type: Floor to ceiling integrated installation;

Product functions: card swiping start stop, card swiping billing, scan code billing.

The 7-inch LCD display screen is designed with humanization, which can clearly display the charging amount and device status. The split type DC charging stack consists of a charging main cabinet and charging terminals. It can intelligently and flexibly switch charging modules according to the BMS charging needs of electric vehicles, improve the utilization rate of charging modules, and reduce comprehensive investment costs. It is suitable for medium and large charging stations such as high-speed service area stations, bus operation stations, and social operation stations.

Product parameters

model		JSDC-360/750/9-4G	JSDC-400/750/10-4G	JSDC-480/750/12-4G
product name		Split type DC charging station(JSDC750-360KW/400KW/480KW/600KW/720KW)
input	rated voltage（Vac）	380V（Three-phase five-wire system，3W+N+PE）±15%
	Frequency range（Hz）	50∽60
	Power factor	≥0.99
output	Charging interface	8 DC fast chargers	10 DC fast chargers	12 DC fast chargers
	Output voltage（Vac）	200-750VDC	200-750VDC	200-750VDC
	output power（KW）	360	400	480
	output current（A）	250	250	250
	DC fast charging terminal power configuration	Each gun has six power specifications：0、40、80、120、160、180KW
	Maximum output power of liquid cooled overcharge terminal	（customizable）	（customizable）	（customizable）
Equipment information	Charging gun length	DC fast charging: 5-meter national standard
	Cooling method	Intelligent air cooling
	efficiency	≥96%
	noise（dB）	≤65%
	stabilized current precision	≤±1.0%
	Voltage stabilization accuracy	≤±0.5%
	Output current error	≤±1.0%
	output voltage error	≤±0.5%
	Uneven current distribution	≤±5.0%
	Current harmonics（THDI）	≤5%
	operation temperature（℃）	-40~+60
	storage temperature（℃）	-40~+70
	Working humidity	5~95%
function characteristics	Basic configuration	Payment methods: contactless CPU charging card, scan code payment BMS auxiliary voltage: 12V/24V switching Charging billing: DC energy meter Communication interface: Ethernet
	Select Configuration	Charging gun length: 5 meters, 7 meters, 10 meters Communication interface: 4G wireless communication module
	basic protection	Charging gun temperature detection, overvoltage/undervoltage protection, overload protection, short circuit protection, over temperature protection, lightning protection
